TPIC6C596 8-Bit Shift Register Module – 7-Segment LED Driver

Overview:
The TPIC6C596 module is an 8-bit serial-in, parallel-out shift register with high-current open-drain outputs. It is commonly used to drive 7-segment LED displays, LED bars, and other high-current loads while reducing the number of control pins required. The module supports cascaded operation for expanding output channels.

Specifications:

• IC Model: TPIC6C596

• Register Type: 8-bit serial-in / parallel-out

• Output Type: Open-drain

• Interface: Serial (SPI-like)

• Operating Voltage: 4.5V – 5.5V

• Output Current: Up to 100mA per channel

• Typical Use: 7-segment LED and LED driver applications
